DRAWWORKS:

Cabot 900 series trailerized Drilling Unit with Model 2346 single drum 900 HP torque converter drive hoist powered by

two 3406C TA Caterpillar engines (425 HP each).

PUMPS:

THREE Gardner Denver PZ-9 (1,000 HP each) powered by THREE separate Caterpillar 3508 diesel engines (900 HP each).

TWO available for parallel operation with one as standby.

MAST:

Cabot Model 112-350 mast with 97' 7" clear height with 15' floor. Hook capacity (10 lines) 365,000 lbs.

Racking capacity 12,800' 4" O.D. drill pipe.


TOP DRIVE:

JH Oilfield DQ-40YA-JH 250 Ton Hydraulic Top Drive with independently powered

CAT C-15 hydraulic Power Unit (CAT C-15 engine).

Rated at 540 continuous horsepower.  25,800 maximum continuous Drilling (Rotary) Torque


SUBSTRUCTURE:

  Cross type, single piece, telescoping, maximum floor height 15'; bottom of rotary beam 12' 3"; overall dimensions of 40' length 12' width.

Rotary capacity 350,000 lbs. Set back capacity 200,000 lbs with total simultaneous capacity of 550,000 lbs.


DRILL COLLARS:
Twenty 6 1/4" x 2 13/16" drill collars with 4 1/2" XH connections.

DRILL PIPE:
  4", 14 lb. grade "S-135" full hole.

BLOW OUT PREVENTERS:
One 11" 3,000 lb.  Annular BOP; hydraulically controlled by Koomey 60 gallon accumulator and control unit.
 One Cameron 11" 5,000 lb.  type "U", double gate furnished with 4" DP rams and blank rams.
NOTE:  includes spool on bottom for 3000 # casing head for most low pressure wells.
One 5,000 LB choke manifold.

MUD TANKS:
One 500 barrel capacity modular-type mud system  including one 75 BBL slugging/pill mixing compartment.
One 6 cone desander.
One Brandt 16 cone mud cleaner, agitators, and mixing equipment.
One RUFF RL-436, high speed, linear motion shale shaker.

MISCELLANEOUS EQUIPMENT:
Separate Toolpusher and Rig Crew living quarters.
Air compressor/accumulator skid.
Generator house with two CAT 3406 GEN sets (3250 KW each).
100 barrel drill water tank.
Fuel tank and other miscellaneous equipment to drill with 4" drill pipe.
